Bad Fuel Pump?

Hey guys,

I'm having some odd problems with the Intrepid lately. I think there I have a problem with my fuel pump. The symptoms are hard starts. It takes a good 10-15 seconds to start the car but it will start. It has backfired a couple times while trying to start. I tested every injector and they all came back withing the 12 ohm resistance range. I do not see any evidence of fuel injector leaking. (Smells like gas, seeing fuel trapped in cylinders...etc.

When I hook a gauge up to the fuel rail and turn the key it reads zero pressure. If I flip the key back back and fourth between ignition and off the gauge still reads at zero. After I get it started, the gauge will go to about 45 pounds of pressure. After I shut off the engine the gauge immediately goes down to zero. Once it did this, i then removed the plenum looking for any signs of an injector leaking gas, to which I did not find any.

Does anyone have any other ideas, or should I just replace the pump? I am thinking the regulator is bad and thus the drain back. This will be the second time I replaced the pump as I replaced about 50,000 miles ago after the other one started acting up.

Gorm is offline
Sponsored Links
Advertisement

post #2 of 22 (permalink) Old 05-30-2012, 12:54 AM
I hit shit with sticks!



Daytrepper's Avatar

Join Date: Jan 2005
Location: Zebulon, NC
Posts: 34,211
Feedback: 20 / 100%

Garage
Definite indicator of a bad fuel pump....gauge should snap to 41-57 psi KOEO....shouldnt lose more than 10 lbs in 15 mins....also KOEO....

This is assuming your gauge is accurate, ASD relay is good, (and ECM signals to it are good), crankshaft sensor is good, and there are NO trouble codes.

If your running an aftermarket pump, wouldnt be surprised if it was bad again.

Last edited by Daytrepper; 05-30-2012 at 12:57 AM.
Daytrepper is online now
post #3 of 22 (permalink) Old 05-30-2012, 10:14 AM Thread Starter
Intrepid Pro

Gorm's Avatar

Join Date: Jan 2003
Location: Iowa
Posts: 7,101
Feedback: 20 / 100%

Quote:
Originally Posted by Daytrepper View Post
Definite indicator of a bad fuel pump....gauge should snap to 41-57 psi KOEO....shouldnt lose more than 10 lbs in 15 mins....also KOEO....

This is assuming your gauge is accurate, ASD relay is good, (and ECM signals to it are good), crankshaft sensor is good, and there are NO trouble codes.

If your running an aftermarket pump, wouldnt be surprised if it was bad again.
I think the gauge is accurate as it does get pressure after the engine is started and runs at 45 ish PSI. I have no reason to suspect the gauge just from appearance. I suppose i could hook it up to the Jeep and check.

While troubleshooting the starting problems, I did swap out the cam and crank sensors, so both are new.

But no codes other than the battery disconnect 50 start code :(
Gorm is offline
post #4 of 22 (permalink) Old 05-30-2012, 09:53 PM
Intrepid Newbie

2000Red-R/T's Avatar

Join Date: Nov 2006
Location: Minnesota
Posts: 93
Feedback: 3 / 100%

X2 on the bad fuel pressure regulator. Backfire would be from a momentary lean condition caused by no/low fuel pressure when trying to start. If you turn the key to the start position and let the pump prime the system then wait a couple of seconds before turning to start position will it fire right up? So anyways my .02 is on the pump!
2000Red-R/T is offline
post #5 of 22 (permalink) Old 05-30-2012, 10:17 PM
Intrepid Pro

Adpros's Avatar

Join Date: May 2012
Location: East Saint Louis Co
Posts: 1,757
Feedback: 5 / 100%

X3 on the pump. Classic pump gone bad symptoms. Now, go look at the post on cutting a hole on the floor for access w/o removing the tank. It is a great post with pics and all!
Adpros is offline
post #6 of 22 (permalink) Old 05-31-2012, 02:40 PM Thread Starter
Intrepid Pro

Gorm's Avatar

Join Date: Jan 2003
Location: Iowa
Posts: 7,101
Feedback: 20 / 100%

Quote:
Originally Posted by Adpros View Post
X3 on the pump. Classic pump gone bad symptoms. Now, go look at the post on cutting a hole on the floor for access w/o removing the tank. It is a great post with pics and all!
LOL. It would probably be easier to drop the tank than to remove my sound system to cut a hole!
New pump is going in tonight.
Gorm is offline
post #7 of 22 (permalink) Old 05-31-2012, 02:54 PM
I hit shit with sticks!



Daytrepper's Avatar

Join Date: Jan 2005
Location: Zebulon, NC
Posts: 34,211
Feedback: 20 / 100%

Garage
Quote:
Originally Posted by Gorm View Post
LOL. It would probably be easier to drop the tank than to remove my sound system to cut a hole!
New pump is going in tonight.
No reason to cut a hole in this car, or any car for that matter.

Its about a 20 minute job to remove the tank on one of these with air tools. No big deal.
Daytrepper is online now
post #8 of 22 (permalink) Old 05-31-2012, 10:19 PM
Intrepid Pro

Adpros's Avatar

Join Date: May 2012
Location: East Saint Louis Co
Posts: 1,757
Feedback: 5 / 100%

Quote:
Originally Posted by Daytrepper View Post
No reason to cut a hole in this car, or any car for that matter.

Its about a 20 minute job to remove the tank on one of these with air tools. No big deal.
You're starting to sound like one of the peeps who write the book times for warranty repairs. I've got a room full of guys who would like to talk to you. LOL!
Adpros is offline
post #9 of 22 (permalink) Old 06-01-2012, 04:05 PM
Intrepid Modder

Join Date: Jan 2005
Location: Novato CA
Posts: 628
Feedback: 0 / 0%

Quote:
Originally Posted by Adpros View Post
X3 on the pump. Classic pump gone bad symptoms. Now, go look at the post on cutting a hole on the floor for access w/o removing the tank. It is a great post with pics and all!
car runs out of gas when tank is 1/2 full
stlrj is offline
post #10 of 22 (permalink) Old 06-01-2012, 04:36 PM
I hit shit with sticks!



Daytrepper's Avatar

Join Date: Jan 2005
Location: Zebulon, NC
Posts: 34,211
Feedback: 20 / 100%

Garage
Quote:
Originally Posted by Adpros View Post
You're starting to sound like one of the peeps who write the book times for warranty repairs. I've got a room full of guys who would like to talk to you. LOL!
I dont think ive ever had one take more than 20 minutes to drop. Except maybe my car once when one of the sway bar bolts wouldnt come out. IIRC it paid 1.8 hours or something like that and you could drop the fuel tank and swap the pump in about .9.
Daytrepper is online now
post #11 of 22 (permalink) Old 06-01-2012, 06:44 PM
Intrepid Pro

Adpros's Avatar

Join Date: May 2012
Location: East Saint Louis Co
Posts: 1,757
Feedback: 5 / 100%

Invariably, (While doing any job that requires fuel tank removal), The customer manages to "Do us a favor" and fills the tank all the way up. This leads to dragging out the fuel recovery unit and waiting for it to pump the tank down to a manageable level. (Time added). Then doing the job, only to find out the parts dept. has ordered the wrong part. (More time added). Then realizing some S.O.B. who has the day off, managed to break the recovery unit so it won't switch to re-fill. Then, after fixing the damn thing, putting the correct part in and re-installing the tank, finally finishing the job.

Yes, on paper and by the book it looks soooo easy to do this but, in the real world, (At least mine), there are complications that lead to holes cut in the floor. I think someone had posted about lifting the bed on a truck. Yes, that is how I regularly do that job. Anything to keep from removing a tank somehow seems to be a benefit. IMHO
Adpros is offline
post #12 of 22 (permalink) Old 06-01-2012, 07:04 PM
Intrepid Fan

Join Date: Dec 2011
Location: toronto
Posts: 247
Feedback: 0 / 0%

i just love the simplicity of the "cut hole in floor" maneouver...simply beautiful....hehehe
ludvig is offline
post #13 of 22 (permalink) Old 06-01-2012, 09:05 PM
I hit shit with sticks!



Daytrepper's Avatar

Join Date: Jan 2005
Location: Zebulon, NC
Posts: 34,211
Feedback: 20 / 100%

Garage
Quote:
Originally Posted by Adpros View Post
Invariably, (While doing any job that requires fuel tank removal), The customer manages to "Do us a favor" and fills the tank all the way up. This leads to dragging out the fuel recovery unit and waiting for it to pump the tank down to a manageable level. (Time added). Then doing the job, only to find out the parts dept. has ordered the wrong part. (More time added). Then realizing some S.O.B. who has the day off, managed to break the recovery unit so it won't switch to re-fill. Then, after fixing the damn thing, putting the correct part in and re-installing the tank, finally finishing the job.

Yes, on paper and by the book it looks soooo easy to do this but, in the real world, (At least mine), there are complications that lead to holes cut in the floor. I think someone had posted about lifting the bed on a truck. Yes, that is how I regularly do that job. Anything to keep from removing a tank somehow seems to be a benefit. IMHO
Never emptied a tank. Used a transmission jack to lower the full tank. Kept spare hose plugs for the full ones to prevent fuel spill. Cake walk. Took a full 42 gallon tank down out of a dodge van one time to swap the pump, no problem. Lowered it about 2 feet, popped the new fuel pump in, back up, done. There are a few exceptions such as some Camaros but you dont run into that very much.

Never did get removing the bed on a truck to change the pump. 6 bolts+, which are often seized up, not to mention lifting the huge bed off, then lining it back up to reinstall, (and risking dents/damage/scratches) when you can strap a transmission jack under the tank, or a good floor jack, secure it, disconnect the filler pipe, and have it down in a few minutes.

To each their own method, everyone has one.


Quote:
Originally Posted by ludvig View Post
i just love the simplicity of the "cut hole in floor" maneouver...simply beautiful....hehehe
For lack of a better description, cutting a hole in the floor is a hack job, IMO. Plus, how are you going to properly seal and paint the hole from the underside and prevent it from rusting out or leaking water in the future? Like I said before, to each their own.


1998 Dodge Intrepid
Ram Logistics Director; Danbo Truck & Diesel, Inc.
Proud sponsor of Just Junk It, LLC
President, Danbo Drumming Ventures, GmbH; Danbo-On-Drums
Daytrepper is online now
post #14 of 22 (permalink) Old 06-01-2012, 09:24 PM
Intrepid Newbie

2000Red-R/T's Avatar

Join Date: Nov 2006
Location: Minnesota
Posts: 93
Feedback: 3 / 100%

Have to agree with Daytrepper on cutting a hole in the floor. Also what about the liability of cutting a hole and if it's not properly sealed, carbon monoxide could build up in the cabin, How about the posibility of a fire penetrating through the hole you cut in the floor (if there was a fire under the car)! It's just best to follow how it's done in FSM. So what if it would take's a little longer to do it right!
2000Red-R/T is offline
post #15 of 22 (permalink) Old 06-01-2012, 09:36 PM
Bitches be like...



beeblebrox82's Avatar

Join Date: Nov 2007
Location: Holland, MI
Posts: 16,548
Feedback: 6 / 100%

Garage
I live in the rust belt and I dropped my 10 year old tank a couple years back with no incident. Piece of cake. I didn't even have a trans jack... that would have been brilliant lol.
beeblebrox82 is offline
