BH1992 Mods Thread 02 ES - Lots of Pics

Before pics:
Dull Lighting




Regular Halogen Low Beams (more yellow than the picture shows)


Very Much a Base Model
no otis or auto dim mirror

vinyl center console lit, regular pop-out cupholders, and plastic shift knob (not pictured)




Yesterday's Work
Not worth trying to pull the original roof harness from the headliner. It only had 3 wires for the lights. I just cut the ends off so it wouldn't get in the way and ran the new harness right up there with it. Nobody would ever see the difference.



After Pics








More to come..

Last edited by bh1992; 04-27-2014 at 12:04 PM.
bh1992 is offline
Sponsored Links
Advertisement

post #2 of 25 (permalink) Old 04-27-2014, 12:07 PM Thread Starter
Intrepid Pro

bh1992's Avatar

Join Date: Jun 2011
Location: Osceola, IA
Posts: 6,311
Feedback: 1 / 100%

Garage
Mods so far include swapping out the roof harness so I could add an overhead console, swapping out all 194 interior light bulbs for LEDs, adding an auto headlight switch, auto dimming rearview mirror, chrome door handles, molded style cupholder, leather center console lid, and chrome shift knob.
bh1992 is offline
post #3 of 25 (permalink) Old 04-27-2014, 12:57 PM
Intrepid Pro

98IntrepidTan's Avatar

Join Date: Dec 2008
Location: Georgia, USA
Posts: 3,254
Feedback: 0 / 0%

Did you install the in-dash light sensor for the auto headlights?
98IntrepidTan is offline
Sponsored Links
Advertisement

post #4 of 25 (permalink) Old 04-27-2014, 01:19 PM Thread Starter
Intrepid Pro

bh1992's Avatar

Join Date: Jun 2011
Location: Osceola, IA
Posts: 6,311
Feedback: 1 / 100%

Garage
Yup. Micholob came over and helped out with dremeling out the hole for it. He also worked on installing the door handles and the switch for the headlights while I reinstalled the headliner (kind of a PITA even with another person holding it).
bh1992 is offline
post #5 of 25 (permalink) Old 04-27-2014, 03:03 PM
Intrepid Pro

YesImLDS's Avatar

Join Date: Mar 2012
Location: Columbia, Missouri
Posts: 2,757
Feedback: 1 / 100%

Looks good. I'm from western Illinois and I do a lot of traveling into iowa and Missouri might have seen ya at one point ha!
YesImLDS is offline
post #6 of 25 (permalink) Old 04-27-2014, 04:38 PM Thread Starter
Intrepid Pro

bh1992's Avatar

Join Date: Jun 2011
Location: Osceola, IA
Posts: 6,311
Feedback: 1 / 100%

Garage
Hard telling, I'm usually on the road between Osceola and Des Moines. I make an occasional trip to NE Missouri. Don't head east very much.
bh1992 is offline
post #7 of 25 (permalink) Old 04-27-2014, 09:26 PM
Intrepid Pro

YesImLDS's Avatar

Join Date: Mar 2012
Location: Columbia, Missouri
Posts: 2,757
Feedback: 1 / 100%

Yeah well I'm never actually driving my m, but the company hhr which is miraculous....
YesImLDS is offline
post #8 of 25 (permalink) Old 05-05-2014, 12:30 AM Thread Starter
Intrepid Pro

bh1992's Avatar

Join Date: Jun 2011
Location: Osceola, IA
Posts: 6,311
Feedback: 1 / 100%

Garage
More pictures and still more work to be done. Today's project was cleaning up the headlights and installing the HID kit.

Before pics




After Refinishing




I used a Turtlewax brand kit. Both lenses had a cloudy look especially on the upper halves. The original protective coating was wearing through. The sanding pads included in the kit weren't rough enough to clean it up much so I took a piece of 1,000 grit and did most of the work with that. They're not perfect but its a great improvement.

And now the difference between Halogen and HID



Wish I could have gotten a before pic of the regular halogen bulbs but for some reason my camera wanted to make the yellow-ish colored halogens look pure white so I threw those pictures out.
bh1992 is offline
post #9 of 25 (permalink) Old 05-17-2014, 11:31 PM Thread Starter
Intrepid Pro

bh1992's Avatar

Join Date: Jun 2011
Location: Osceola, IA
Posts: 6,311
Feedback: 1 / 100%

Garage
Swapped out the 5000k bulbs for 4300k. The 35w 5000k had a blue-ish tint that wasn't very bad, but enough to annoy me. 4300k is nice and white.

Got around to doing a couple more mods today. Still got more to do. Here's a couple pics.


bh1992 is offline
post #10 of 25 (permalink) Old 05-18-2014, 08:10 AM
Intrepid Pro

Join Date: Feb 2002
Location: Virginia, U.S.
Posts: 16,056
Feedback: 4 / 83%

I'm always a fan of the later Concorde black Gage's - especially with the dark interior.
peva is offline
post #11 of 25 (permalink) Old 05-18-2014, 05:04 PM
Intrepid Modder

Join Date: Oct 2012
Location: USA
Posts: 738
Feedback: 0 / 0%

Lookin good.
SRT6INTREPID is offline
post #12 of 25 (permalink) Old 05-18-2014, 06:30 PM Thread Starter
Intrepid Pro

bh1992's Avatar

Join Date: Jun 2011
Location: Osceola, IA
Posts: 6,311
Feedback: 1 / 100%

Garage
I think its going to be looking even better tonight. Got my led strips and glovebox light installed today. Also changed the backlighting on the instrument cluster from the standard green to blue last night at 3am. Figure I'll try to post a video later tonight but I'm not sure exactly what all I might have to do for posting videos. Photobucket or Youtube maybe? Either way I should be able to post it up on the LH Owners of America page on facebook without a problem. Still need to install the door lights in all 4 doors and install the last two chrome door handles.
bh1992 is offline
post #13 of 25 (permalink) Old 05-18-2014, 06:33 PM
Intrepid Pro

KxWarrior's Avatar

Join Date: Jul 2012
Location: Harrisburg Area PA
Posts: 1,797
Feedback: 3 / 100%

Garage
Quote:
Originally Posted by bh1992 View Post
I think its going to be looking even better tonight. Got my led strips and glovebox light installed today. Also changed the backlighting on the instrument cluster from the standard green to blue last night at 3am. Figure I'll try to post a video later tonight but I'm not sure exactly what all I might have to do for posting videos. Photobucket or Youtube maybe? Either way I should be able to post it up on the LH Owners of America page on facebook without a problem. Still need to install the door lights in all 4 doors and install the last two chrome door handles.
Just out of curiosity, What would I pull from a door, to get those door lights in the back? I was considering doing that at some point along the line.

Youtube is probably easier, but I use photobucket for all my older stuff.
KxWarrior is offline
post #14 of 25 (permalink) Old 05-18-2014, 06:42 PM Thread Starter
Intrepid Pro

bh1992's Avatar

Join Date: Jun 2011
Location: Osceola, IA
Posts: 6,311
Feedback: 1 / 100%

Garage
The door lights are the same for front and rear. Pull the lens cover off. Remove the plastic piece behind it that holds the light bulb, and I just cut off the pigtail about 6" from the light. Could possibly pull the whole door harnesses but I got these parts out of a 99 M so I'm pretty sure they wouldn't interchange. I'm going to have to run wires from the yellow and pink courtesy light power supply on the roof harness down to each door.
bh1992 is offline
post #15 of 25 (permalink) Old 05-18-2014, 06:43 PM Thread Starter
Intrepid Pro

bh1992's Avatar

Join Date: Jun 2011
Location: Osceola, IA
Posts: 6,311
Feedback: 1 / 100%

Garage
I also ordered some 212-2 led lights off ebay to go in place of the regular tube shaped bulb.
